"T" Arm and Hardware
Item
Number Part Number Description Note
Quantity Per
Package Assembly
8881011810 Pad, Arm, Desk Length w/ Law Label 1 1 1 A
8881011813 Pad, Arm, Full Length w/ Law Label 1 1 1 A
1055205 Package, Screw Phillips Pan Head (#10-32 x 1-3/8") 2 1 2
1069639 T-Arm Assembly w/ Plug Buttons, Desk Length, Low
Range, Black 1 1 3
1069643 T-Arm Assembly w/ Plug Buttons, Full Length, Low
Range, Black 1 1 3
1069641 T-Arm Assembly w/ Plug Buttons, Desk Length,
High Range, Black 1 1 3
1069645 T-Arm Assembly w/ Plug Buttons, Full Length, High
Range, Black 1 1 3
1027095 Plug Button, Black (7/8") 1 2 4
1069635 Post, Arm, Low Range 1 1 5
1069637 Post, Arm, High Range 1 1 5
1073424 Kit, Clothing Guard, Low Range - Right 1 1 6
1073425 Kit, Clothing Guard, Low Range - Left 1 1 6
1073422 Kit, Clothing Guard, High Range - Right 1 1 6
1073423 Kit, Clothing Guard, High Range - Left 1 1 6
1069652 Guard, Clothing, Low Range 1 1 7
1069651 Guard, Clothing, High Range 1 1 7
1069634 Tube, Support, Low Range, Black - Right 1 1 8
1073247 Tube, Support, Low Range, Black - Left 1 1 8
1069650-NLA NLA - Tube, Support, High Range, Black - Right 1 1 8
1073246 Tube, Support, High Range, Black - Left 1 1 8
1028427 Grip, Foam 1 1 9
1025731 Locknut (#10-32) 1 1 10
1076839 Lever, Locking 1 1 11
1025716 Screw, Phillips Pan Head (#10-32 x 11/16") 1 1 12
1073196 Spring, Torsion 1 1 13
1006773 Screw, Socket Button Head (1/4-20 x 1/2") 1 3 14
1075069 Clamp, Clothing Guard - Right 1 1 15
1075070-NLA NLA - Clamp, Clothing Guard - Left 1 1 15
1069627 Arm Socket Assembly, Clamp On 1 1 16
1069605 Clamp, "T" Arm Socket - Inside 1 1 17
1026907 Washer (1/4 x 1/2 x 1/16") 1 3 18
1055298 Screw, Hex Head (1/4-28 x 1-5/8") 1 3 19
1075162 Clamp, "T" Arm Socket - Outside 1 1 20
1055346 Screw, Hex Head (1/4-28 x 3/4") 1 4 21
1026108 Lockwasher (1/4 x 15/32 x 1/64") 1 4 22
1069620 Bracket, Socket, Black 1 1 23
1069609 Insert, Arm Socket, Black 1 2 24
1058545 Lever, Actuator 1 1 25
See Chart "T" Arm Kits 1 1 B
21
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 00-131
