Axle Tube Position Assembly
For Suspension Chairs, it is recommended that Axle Tube Position Assemblies be replaced in pairs. First,
select a Rear Suspension Assembly. Second, select a Positioning Tube.
When ordering, please state if the Rear Suspension Assembly and Positioning Tubes are to be factory
assembled.
#1 Rear Suspension Assembly
User's Weight
Range
Part
Number
Spring Color
Blue/Blue 1093150-NLA 0 lbs to 100 lbs
Blue/Black 1093151-NLA 101 lbs to 140 lbs
Black/Black 1093152-NLA 141 lbs to 180 lbs
Black/Purple 1093153-NLA 181 lbs to 220 lbs
Purple/Purple 1093154-NLA 221 lbs to 250 lbs
36
