8 Intel ® Xeon™ Processor, Intel ® E7520 Chipset, Intel ® 6300ESB ICH Development Kit User’s Manual
Product Overview
1.3 Products Feature List
• Processor Support
— Dual Intel
®
Xeon™ Processors
— On-board processor voltage regulators compatible with VRM/EVRD 10.1 Design Guide
• Clocking
— CK409B clock synthesizer that generates all host clock and the PCI Express* interface
clock for the MCH PHY Layer
— DB800 generates the PCI Express differential pair clocks to the onboard PCI Express
components and the dedicated PCI Express slots
• Memory Support
— Registered, ECC, DDR2 400
— Each of the two memory channels on the Intel
®
E7520 in this CRB supports a maximum
of two DDR2 400 DIMMs per channel
— The maximum supported DDR2 400 memory configuration is 8 Gbyte using different
combinations of single and dual ranked, x4, 1 Gbyte technology DIMMs (limit of up to
four ranks per channel)
— 3.2 Gbytes/s bus per channel bandwidth with DDR2 400
• I/O slot support
— One PCI-X 133 MHz slot from PXH
— Two PCI-X 100 MHz slots from PXH
— One PCI Express x8 slot
— One PCI Express x4 slot
— One 5 V PCI-32/33 slot connected through the Intel
®
6300ESB I/O Controller
— Two 3.3 V PCI-X 64/66 slots connected through the Intel
®
6300ESB I/O Controller
• Low Pin Count Bus
— National* LPC 47M172 Super I/O residing on LPC bus
— LPC card header for debug purposes only
— Firmware hub
• IDE ATA 100 support
— Two ATA-100 IDE connectors supported
• S-ATA support
— Two S-ATA connectors
• USB Support (Four Channels)
— Two USB 2.0 connectors
— Two USB 2.0 headers
• Back Panel I/O
