Heatsink Assembly
Heatsink Assembly
7
This section provides heatsink assembly instructions for the Intel
®
Xeon™ Processor with 800
MHz System Bus, Intel
®
E7520 Chipset, and Intel
®
6300ESB ICH Development Kit:
Components requiring post-secondary heat sink assembly are listed in
Table 9.
Components Requiring Heat Sink Assembly
Component
Quantity per
Board
Heat Sink
Manufacturer
Part Number
Comments
Processors
(See
.)
Up to 2
Cooler Master
E3W-N73CS-I1
Active heat sink + back plate.
Figure 11.
Components Requiring Heat Sink Assembly
Processors
(2)
