ZyAIR B-4000 Hot Spot Gateway
4-6 WAN, LAN and Server Setup
The following table describes the labels in this screen.
Table 4-1 WAN/LAN
LABEL DESCRIPTION
LAN
IP Address Enter the LAN IP address of the ZyAIR in dotted decimal notation. The default is
192.168.1.1.
Subnet Mask Enter the LAN subnet mask in dotted decimal notation. The default is
255.255.255.0.
WAN MAC Address Select Default to use the factory assigned MAC address.
If your ISP requires MAC address authentication, select Change to and enter the
MAC address of a computer on the LAN in the fields provided.
WAN Port Mode
DHCP Client Select this option to set the ZyAIR to act as a DHCP client on the WAN. The
ZyAIR obtains TCP/IP information (IP address, DNS server information, etc.)
from a DHCP server. This is the default setting.
Static IP Select this option to set the ZyAIR to use a static (or fixed) IP address.
IP Address Enter the static IP address in dotted decimal notation.
Subnet Mask Enter the subnet mask in dotted decimal notation.
Gateway IP address Enter the IP address of the default gateway device.
Primary/Secondary
DNS Server
Enter the IP addresses of the primary and/or secondary DNS servers.
PPPoE Select this option to activate PPPoE support. Refer to Section 4.6 for more
information.
Username Enter the user name exactly as your ISP assigned. If assigned a name in the
form user@domain where domain identifies a service name, then enter both
components exactly as given.
Password Enter the password associated with the user name above.
PPP MTU Setting Enter the MTU (Maximum Transfer Unit) size.
TCP MSS Setting Enter the MSS (Maximum Segment Size) size.
Service Name Enter the name of your PPPoE service.
