ZyAIR B-4000 Hot Spot Gateway
Cable Types and Cable Pin Assignments I-3
Chart I-5 LAN Port Cable Pin Assignments
ETHERNET DEVICE
(COMPUTER/ UPLINK PORT)
ZYAIR
1 TD+
1 RD+
2 TD-
2 RD-
3 RD+
3 TD+
6
RD-
6
TD-
The DEVICE Port
The following table describes the printer cable pin assignments that the ZyAIR’s device port uses with the
exclusive printer.
Chart I-6 Device Port Cable Pin Assignments
ZYAIR
DB25
EXCLUSIVE
PRINTER
RJ-11
2
2
3
3
7
4
5
5
