Parts List
8
Ref #
Part #
Description
Qty Ref #
Part #
Description
Qty
95
402-00077 Philip Screw M2.5x6
2
143 413-00018 FAN HARNESS, 13-0081
1
96
402-00078 Washer 2.5x5x0.5mm
2
144 407-00007 MOTOR CONTROLLER, 08-0158
1
97
402-00079 SPRING WASHER 2.5MM
2
145 407-00008 EKG MODULE, 07-0080
1
98
402-00080 GEAR WASHER D2.5
2
146 413-00019 TEL-LINE
1
99
402-00048 PAN SPRING WASHER 10*19*0.25
6
147 407-00006 SPEED INCLINE PCB, 07-0079
2
100
402-00138 PHILLIP SCREW M4X16
4
148 407-00103 CONSOLE PCB, 4 WIN 07-0095 LEGACY
1
101
410-00016 BELT GUIDE BRACKET
2
149 412-00005 ACTUATOR, 12-0045
1
102
406-00057 POWER CORD SPACER
1
150 408-00043 MEMBRANE, SPEED LEGACY
1
103
406-00119 HANDLE CAP, 150T.1/220T.1/320T.1
1
151 408-00044 MAMBRANE, INCLINE LEGACY
1
104
406-00079 BASE BUMPER, 28*25*13
2
152 406-00157 SPEAKER GRILL 60.X10.6, LEGACY
2
105
402-00082 WASHER 9*22*2
4
153 414-00002 SAFETY KEY DECAL, IN-008
1
106
402-00083 Spring Washer 10
4
154 402-00086 PHILIP SCREW, 10-24 X 42.5
1
107
402-00031 PHILIP SCREW ST4.2*13
3
155 402-00087 SCREW 8/32*16
1
108
402-00031 PHILIP SCREW ST4.2*13
47
156 402-00088 WASHER
1
109
402-00085 Philip Screw 10-24"*12mm
1
157 414-00082 OVERLAY, LEGACY
1
110
402-00100 PHILIP SCREW 4.2*25
2
158 414-00112 DECAL, HR RECEIVER BLACK LEGACY
1
111
402-00099 ALLEN BOLT M5*8
2
159 402-00033 SCREW ST2.9*13
6
112
402-00012 ALLEN BOLT M8*40
2
160 407-00020
HRC RECEIVER DIRECTION TECH, 07-0090
1
113
402-00124 PHILIP SCREW, M6 X 10
2
161 402-00146 FLATHEAD SCREW, ST4.2X16
12
114
414-00071 DECAL LEFT SIDE PLATFORM, LEGACY
1
162 406-00159 CONTROLLER SUPPORT BRACKET, LEGACY
1
115
414-00070 DECAL FOLD-UP, LEGACY
1
163 406-00160 SUPPORT BRACKET, LEGACY
2
116
415-00051 OWNERS MANUAL LEGACY
1
164 402-00033 SCREW ST2.9*13
8
117
406-00061 DECK BUMPER 41*3
2
165 413-00041 POWER CORD, TFT FIRST LEGACY
1
118
402-00088 WASHER
6
166 413-00042 POWER CORD, TFT SECOND LEGACY
1
119
402-00081 Plastic Washer
6
167 413-00043 HARNESS, POWER LEGACY
1
120
402-00093 GEAR WASHER
1
168 413-00044 CORD, LEGACY
3
121
402-00098 PHILIP SCREW ST2.9*6.5
13
169 407-00032 TV , TFT LEGACY
1
122
402-00031 PHILIP SCREW ST4.2*13
8
170 413-00045 ADAPTER, LEGACY
1
123
402-00123 PHILIP SCREW, ST4 X 25
2
171 406-00167 KEY FOR TFT, LEGACY
1
124
410-00014 ALLEN WRENCH HANGER
1
172 413-00046 AV SET, LEGACY
1
125
410-00045 ALLEN WRENCH, 75*5
1
173 406-00168 TWIST TIE, LEGACY
1
126
410-00023 ALLEN WRENCH 3/16"
1
174 407-00033 SPEAKER, LEGACY
2
127
410-00024 ALLEN WRENCH 7/32"
1
175 413-00047 EARPHONE SET, LEGACY
1
128
408-00013 SPEED SENSOR
1
176 402-00174 SCREW, ST2.5X7.5
4
129
413-00021 SPD AND INCL HARNESS A
1
177 413-00048 FILTER, LEGACY
1
130
412-00008 MOTOR,12-0057
1
178 413-00049 HARNESS, EKG TO HRC, LEGACY
1
131
406-00046 FAN (MOTOR)
1
179 408-00038 FUSE, LEGACY
1
132
413-00013 CONSOLE HARNESS, 3PC
1
180 406-00168 TWIST TIE, LEGACY
2
133
413-00014 SPEED AND INCLINE HARNESS
2
181 406-00170 HRC RECEIVER HOUSING, LEGACY
1
134
413-00015 EKG HARNESS
2
182 402-00022 SCREW M3*10
4
135
408-00014 FUSE
1
183 402-00181 SCREW, M3X20
4
136
408-00015 CIRCUIT BREAKER IN-011
1
184 402-00182 NUT, NYLON LOCK M3
4
137
407-00005 CONSOLE FAN MOTOR
1
185 402-00183 WASHER, SPRING M3
4
138
413-00016 REED SWITCH
1
186 402-00184 WASHER, 3.2X7X0.5
8
139
413-00017 JUMPER WIRE
1
187 414-00030 DECAL SPEED, IN-044, 150T, 220T, 320T,IN
1
140
408-00017 MAGNET CORE
1
188 414-00024 DECAL ELEVATION, IN-045, 150T, 220T, 320
1
141
413-00004 POWER CORD
1
189 414-00025 DECAL IRONMAN UPRIGHTS, IN-049
2
142
408-00016 TRANSFORMER
1
190 414-00072 DECAL RIGHT SIDE PLATFORM, LEGACY
1
Legacy Treadmill Parts List Rev A (cont.)
