Parts List
Ref #
Part #
Description
Qty Ref #
Part #
Description
Qty
1
423-00055 CROSS BAR, LEGACY
1
48
406-00047 FAN (CONSOLE)
1
2
406-00055 BASE BUMPER, 38*33*15
2
49
406-00042 LEFT SIDEBOARD COVER
1
3
406-00056 LONG BUMPER, 43*35*45
2
50
406-00043 RIGHT SIDEBOARD COVER
1
4
423-00009 LEFT UPRIGHT
1
51
410-00042 LATCH GUIDE, 150T.1/220/320/INSPIRE
1
5
423-00010 RIGHT UPRIGHT
1
52
406-00044 REAR WHEEL
4
6
423-00011 DECK FRAME
1
53
402-00050 POWER METAL BUSHING
9
7
423-00012 BASE, BLACK
1
54
402-00046 CLIP NUT
8
8
419-00007 ELEVATION FRAME
1
55
406-00034 TRANSPORT WHEEL
2
9
419-00008 MOTOR FRAME
1
56
404-00004 POLY V-BELT, 190J8
1
10
405-00020 SIDE BOARD, LATCH SIDE LEGACY
1
57
404-00013 WALKBELT, 20X60 NW RHOMBUS BELT, INSPIRE
1
11
405-00021 SIDE BOARD, RIGHT LEGACY
1
58
403-00005 WALK BOARD, TRIAD
1
12
419-00010 LINKAGE BRACKET
2
59
406-00035 DECK BUMPER, 24*20
8
13
419-00009 REED SWITCH PLATE
1
60
406-00098 GROMMET IRONMAN UPRIGHT
4
14
419-00011 SIDE MOTOR COVER BRACKET
2
61
406-00045 ADJUST SUPPORT
2
15
402-00142 THREADED CAP, LATCH, 150T/220/320.1, INS
1
62
409-00003 FRONT ROLLER, 150T,220T,320T
1
16
402-00143 LATCH PIN, 150T.1/220T.1/320T.1
1
63
409-00004 REAR ROLLER, 150T,220T,320T
1
17
419-00024 LATCH GUIDE PLATE, 150T.1/220T.1/320T.1
1
64
410-00046 GAS SPRING, 400N
1
18
402-00141 SPRING FOR LATCH, 150T.1/220T.1/320T.1
1
65
419-00012 REAR WHEEL SHAFT
4
19
406-00036 MOTOR COVER
1
66
402-00051 SHOULDER ALLEN BOLT 1/4"-20*63.5
2
20
406-00120 LEFT FENDER, 150T.1 (3" LONGER)
1
67
402-00052 SHOULDER ALLEN BOLT 1/4"-20*28.5
2
21
406-00121 RIGHT FENDER, 150T.1 (3"LONGER)
1
68
402-00053 SHOULDER ALLEN BOLT 5/16"-18*45
2
22
406-00039 LEFT END CAP, SILVER (old #06-0213)
1
69
402-00054 Allen Bolt 5/16"-18*15
6
23
406-00040 RIGHT END CAP, SILVER
1
70
402-00055 Allen Bolt 5/16"-18*70
2
24
406-00048 MOLDED REAR PAN
1
71
402-00056 Carriage Bolt 5/16"-18*25.4
9
25
406-00049 FRONT BOTTOM PAN
1
72
402-00057 Carriage Bolt 5/16"-18*19
4
26
406-00050 REAR BOTTOM PAN
1
73
402-00058 Nylon Lock Nut 5/16"-18*8.9
9
27
406-00124 BOTTOM SHEET, INSPIRE
1
74
402-00059 Hex Bolt 3/8"-16*45
1
28
406-00021 MAIN CONSOLE BOX (B)
1
75
402-00060 Hex Bolt 3/8"-16*63.5
1
29
406-00163 LEFT TOP HANDLE COVER, LEGACY
1
76
402-00096 ALLEN BOLT 3/8" -16X35
2
30
406-00164 RIGHT TOP HANDLE COVER, LEGACY
1
77
402-00062 Nylon Lock Nut 3/8"-16*11.5
2
31
406-00024 LEFT POCKET BOTTOM
1
78
402-00063 Nylon Lock Nut 5/16"-18*8.9
1
32
406-00025 RIGHT POCKET BOTTOM
1
79
402-00047 JAM NUT 5/16"*18
4
33
406-00026 LEFT BOTTOM HANDLE COVER
1
80
402-00064 Screw ST4.2*32
2
34
406-00027 RIGHT BOTTOM HANDLE COVER
1
81
402-00065 Screw ST4.8*16
2
35
406-00028 REED SWITCH TOP HOLDER
1
82
406-00059 SQUARE BUMPER, 40*28*6
2
36
406-00029 REED SWITCH BOTTOM HOLDER
1
83
402-00097 PHILIP SCREW ST4*16
39
37
406-00165 CONSOLE B INSERT, 4 WIND LCD, LEGACY
1
84
402-00068 Philip Screw ST4.2x16
44
38
402-00090 KILL SWITCH MAGNET
1
85
402-00069 Philip Screw ST2.9x9.5
15
39
406-00166 FOOT PLATFORM, PLASTIC SUPPORT, LEGACY
2
86
402-00140 SPRING WASHER 6
8
40
406-00030 FAN GRILL
1
87
402-00018 PHILIP SCREW M6*12
8
41
406-00032 FAN MOTOR MOUNT
1
88
402-00139 ALLEN SCREW M8X16
1
42
402-00091 PLASTIC WASHER
2
89
402-00073 Washer 6.6x12x1.6mm
14
43
402-00049 CLIP NUT
3
90
402-00074 Washer 9x16x1.6mm ***USE #402-00026***
10
44
405-00004 T EXTRUSION
1
91
402-00075 Spring Washer 8mm
12
45
405-00005 S EXTRUSION
2
92
410-00020 PULSE RECEPTACLE PLATE - TOP
2
46
406-00041 PLUG CALIBRATION HOLE
1
93
410-00021 PULSE RECEPTACLE PLATE - BOTTOM
2
47
406-00033 DOME END CAP
2
94
402-00076 Philip Screw ST4.2x9.6
4
Legacy Treadmill Parts List Rev A
