Specifications
AMPLIFIER SECTION
Power Output:
100 Watts per channel, min RMS, at 8 ohms,
both channels driven from 20 Hz to 20 kHz,
with no more than 0.08% THD.
Dynamic power output:
2
×
170 Watts at 2 ohms
2
×
135 Watts at 4 ohms
2
×
140 Watts at 8 ohms
Total Harmonic Distortion: 0.08% at rated power
0.08% at 1 watt output
IM Distortion:
0.08% at rated power
0.08% at 1 watt output
Damping Factor:
60 at 8 ohms
Input Sensitivity and Impedance
PHONO:
2.5 mV, 50 kohms
Line (CD, TAPE-1, 2,
VIDEO, DVD):
150 mV, 50 kohms
Video (VIDEO, DVD)
1 Vp-p, 75 ohms
Output Level and Impedance
Line (TAPE-1, 2,
VIDEO):
150 mV, 2.2 kohms
Video (VIDEO,
MONITOR):
1 Vp-p, 75 ohms
Zone 2:
150 mV, 22 kohms
Phono Overload:
120 mV RMS. at 1 kHz, 0.5% T.H.D.
Frequency Response:
20 Hz to 30 kHz : ±1 dB
RIAA Deviation:
20 Hz to 20 kHz : ±0.8 dB
Tone Control
Bass:
±10 dB at 100 Hz
Treble:
±10 dB at 10,000 Hz
Signal-to-Noise Ratio
Phono:
80 dB (IHF A, 5 mV input)
CD/Tape:
100 dB (IHF A)
Muting: –50
dB
TUNER SECTION
FM
Tuning Range:
87.5 to 108.0 MHz (100 kHz steps)
Usable Sensitivity
Mono:
11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo:
17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
50 dB Quieting Sensitivity
Mono:
17.2 dBf, 2.0 µV (75 ohms)
Stereo:
37.2 dBf, 20 µV (75 ohms)
Capture Ratio:
2.0 dB
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
90 dB
Signal-to-Noise Ratio
Mono:
76 dB, IHF
Stereo:
70 dB, IHF
Alternate Channel Att. (±400 kHz)
Mono:
55 dB, IHF
Selectivity:
55 dB DIN (±300 kHz 40 kHz Devi.)
AM Suppression Ratio:
50 dB
Total Harmonic Distortion
Mono: 0.15%
Stereo: 0.25%
Frequency Response:
30 Hz to 15 kHz, ±1.5 dB
Stereo Separation:
45 dB at 1 kHz
30 dB at 100 Hz to 10 kHz
Stereo Threshold:
17.2 dBf, 2.0 µV (75 ohms)
AM
Tuning Range:
530 to 1,710 kHz (10 kHz steps)
Usable Sensitivity:
30 µV
Image Rejection Ratio:
40 dB
IF Rejection Ratio:
40 dB
Signal-to-Noise Ratio:
40 dB
Total Harmonic Distortion: 0.7%
GENERAL
Power Supply:
AC 120 V, 60 Hz
Power Consumption:
2.8 A
Dimensions (W
×
H
×
D): 17-1/8"
Ч
5-7/8"
Ч
13-7/16"
435
Ч
150
Ч
341 mm
Weight:
19.8 lbs. (9.0 kg)
REMOTE CONTROLLER (RC-477S)
Transmitter: Infrared
Signal range:
Approx. 16 ft., 5 meters
Power supply:
Two “AA” batteries (1.5 V
×
2)
Specifications and features are subject to change without notice.
