NPort 5600 Series User’s Manual
Well Known Port Numbers
A-6
RJ45 (8-pins) to Male DB25
NPort 5630
RS-422/
4-wire RS-485
Device
Cable Wiring
3
4
5
6
7
7
2
3
8
5
Male DB25
Female
DB25
RJ45 Connector
RJ45 Port
25 pins
8 pins
TxD+
TxD-
RxD-
RxD+
GND
RxD+
RxD-
TxD-
TxD+
GND
Serial Cables for NPort 5630 (2-wire RS-485)
RJ45 (8-pins) to Female DB9
NPort 5630
2-wire RS-485
Device
Cable Wiring
Male DB9
Female DB9
RJ45 Connector
RJ45 Port
9 pins
8 pins
5
6
7
3
1
7
Data-
Data+
GND
Data-
Data+
GND
RJ45 (8-pins) to Male DB9
NPort 5630
2-wire RS-485
Device
Cable Wiring
Male DB9
Female DB9
RJ45 Connector
RJ45 Port
9 pins
8 pins
5
6
7
2
1
8
Data-
Data+
GND
Data-
Data+
GND
RJ45 (8-pins) to Female DB25
NPort 5630
2-wire RS-485
Device
Cable Wiring
Male
DB25
Female DB25
RJ45 Connector
RJ45 Port
25 pins
8 pins
5
6
7
2
8
4
Data-
Data+
GND
Data-
Data+
GND
