MultiVOIP FXS Quick Start Guide Preliminaries & Info Gathering
15
Phone/IP Details *Absolutely Needed*
Before Starting the Installation
The MultiVOIP will interface with both the IP network and the phone system. You must gather
information about the IP network and about the phone system so that the MultiVOIP can be configured to
operate with them properly. A summary of this configuration information appears on page 16
(“Config Info CheckList”).
Gather IP Information
Ask your computer network
administrator. Info needed to operate:
all MultiVOIP models.
IP Network Parameters:
Record for each VOIP Site
in System
#
• IP Address
• IP Mask
• Gateway
• Domain Name Server (DNS) Info (optional)
Phone/IP Details *Absolutely Needed*
Gather Telephone Information
Analog Phone Parameters
Ask phone company or
telecom manager.
Needed for:
MVPFXS-24
MVPFXS-16
MVPFXS-8
Analog Telephony Interface Parameters:
Record for this VOIP Site
#
• Which interface type is used?
FXS
Loop Start only
• Determine whether the channel will be used for a
phone, fax, or KTS (key telephone system), or perhaps
serve a station card on a PBX.
