USER GUIDE
42
Transmitter, Broadcaster 8/16 Line Splitter/Line Splitter L
Cables
& Connectors VGA In - HDD15M
VGA Local - HDD15F
Stereo audio In/Out – Jack PL 3.5mm
Serial In- DB9F
Serial Local- DB9M
System Out -1/8/16 RJ45
Control – RJ11
Power LED – Green (front panel) System In - RJ45
System Out - RJ45
Control – RJ11
Power LED – Green (front panel)
Dimensions 292.5x 153.6x41.5mm 138x153.7x41.5mm
Power External Adaptor
5VDC 2.5A External Adaptor
5VDC 2.5A
Order Number Transmitter 0VS50005
Broadcaster 8 0VS50003
Broadcaster 16 0VS50004
Line Splitter 0VS50009
Line Splitter L 0VS50002
Receiver/Receiver L Receiver DCL
Cables
& Connectors System In - RJ45
Screen - HDD15F
Audio Out – 3 Jack L,R, L&R
Serial Out- DB9M
Tuning- potentiometer / RJ11
Power LED – Green (on RJ45) System In - RJ45
System Out - RJ45
Screen – 2 x HDD15F
Audio Out -2x 3.5 Jack
, L&R
Serial Out- 2 X DB9M
Tuning- RJ11
Power LED-Green
(on RJ45)
Dimensions 147x 145x26mm
(including mounting) 152x145x26mm (including
mounting)
Power External Adaptor
5VDC
1 or 2.5A
External Adaptor
5VDC 2.5A
Order
number Receiver 0VS50010
Receiver L 0VS50001 Receiver DCL ( Dual Cascade
Long) 0VS50006
Video Tuning Unit
Cables
& Connectors To Receiver- RJ11
3 button tuning
Dimensions 93.7x62.1x28mm
Power Powered from the Receiver or
Line Splitter
Order number Video Tuning Unit 0VS50008
