Minicom Advanced Systems 3000 User Manual
Page 35
USER GUIDE
34
Remote tuner at the
screen
Receivers
Broadcaster
Line Splitter
DS Vision Service
Utility installed here
Player - IP: 192.168.111.132
LAN
Figure 38 Remote tuning
At the player the setup is done as follows:
1.Connect the Serial Download cable to the Broadcaster/Transmitter and player.
2. Open the Service Utility and choose Tools/Options, the Preferences window
appears, see Figure 25 above.
3. Select the Enable Remote Control checkbox, the software starts a small web
server in the background allowing other computers on the network to access it.
The Check Remote Control button un-grays. Click the button to display a local
browser to indicate that the remote option is enabled and functioning.
4. To verify the IP address of the player, click Start/Run, type “cmd” press Enter,
type “ipconfig” press Enter. The IP address appears.
The tuning at the remote laptop/device is done as follows:
1. Open a browser and type the IP address of the player. For example in Figure 38
the remote tuner accesses the tuning facility by typing the IP address
2. Press Enter. A list of all Receivers L, Receivers DCL and Line Splitters
connected to the player appears, see Figure 39.
