Page 35
4-7
3. When the Message “Paper Jam.” Appears
W
h
en
a M
e
ss
age
Appe
ars
Ch
a
p
ter
4
CF911PE Operator’s Manual
Open the Left Door
.
Pull out the sheet of paper from the
Transport Section.
Raise the Guide Plate
, turn Knob
and pull out the sheet of paper.
Press down Guide Plate
and pull out
the sheet of paper.
Close the Left Door
.
Open the Front Door.
Turn Lever
to the left.
Press Guide Plate
, turn Knob
and
pull out the sheet of paper.
Grasp Lever
and slide out the Transfer/
Fusing Unit.
Misfeed in the unit
1
L1
L1
1144O548AA
2
1144L022AA
3
M2
M1
1144L023AA
M2
M1
4
M3
M3
1144L024AA
5
L1
L1
1144O549AA
6
C4119O010AA
7
M4
L2
M5
L2
M4
M5
C4119O016AA
8
M6
M6
1144L027AB
1144L027AB
