GLASS REMOVAL
3 . Loosen and remove the three nuts at the top of the glass door frame.
4 . Carefully lift the glass frame out of the lower channel and remove by angling the frame down to the left
28 L100001
29
GLASS REMOVAL
GLASS FRAME REMOVAL (see Figure 36)
1. Remove the front air panel using a screwdriver to lift from center if necessary.
2. Remove the left and right cover plates by lifting up and moving to the center.
Figure 36 - Removing Glass Frame
and tilting out the upper right corner.
NOTE: Avoid contacting the glass to any
surface and be carefull to not damage
Glass frame
Front air panel
Left cover plate
Right cover plate
any of the controls in the lower cavity.
