271
Practical hints
Replacing bulbs
7 Tabs
̈ Squeeze tabs 7 together and remove
bulb holder.
̈ Gently push bulb into socket, turn
counterclockwise and remove.
̈ Insert new bulb in socket, push in and
turn clockwise.
̈ Reinstall bulb holder. You should hear
it engage.
̈ Insert the tail lamp in the body, lower
edge first. Make sure it engages.
̈ Retighten screws with washers on
them.
License plate lamp
1 License plate lamp
2 Screws
̈ Switch off the lights.
̈ Loosen both screws 2 and remove
lamp.
̈ Replace the tubular lamp and reinstall
lamp.
̈ Retighten the screws.
High mounted brake lamp
1 Cover
2 Tab
̈ Switch off the lights.
̈ Squeeze both sides of cover 1, fold it
forward and remove.
̈ Press tab 2 on reflector and remove
reflector.
̈ Gently push bulb into socket, turn
counterclockwise and remove.
̈ Insert new bulb in socket, push in and
turn clockwise.
