268
Practical hints
Replacing bulbs
Replacing bulbs for front lamps
Replacing low beam bulbs
1 Low beam halogen or Bi-Xenon* head-
lamp cover with locking tab
2 Electrical connector
Bi-Xenon* headlamp
Halogen headlamp
̈ Switch off the lights.
̈ Open the hood ( ୴ page 217).
̈ Push down tab at top end of cover 1
and remove.
̈ Pull electrical connector 2 off.
̈ Unclip the retainer springs and take out
the bulb.
̈ Insert the new bulb so that the base lo-
cates in the recess on the holder.
̈ Clip the retainer springs.
̈ Plug the connector 2 onto the bulb.
̈ Align headlamp cover and click into
place.
Warning!
G
Do not remove the cover 1 for the
Bi-Xenon headlamp. Because of high voltage
in xenon lamps, it is dangerous to replace
the bulb or repair the lamp and its compo-
nents. We recommend that you have such
work done by a qualified technician.
