NET101 User’s Manual -5-
Chapter 1: Introduction
Section 6. NET101 Indicators
NET101 LED Status Indicators
Color
Signal Definition
Condition / Description
Green
Power state
On: Normal power
Red Error
Condition
On: Error condition occurred
Orange Logon
state
On: When there is Master or Driver
logon and receive the image.
Yellow Data
activity
Flash when there is data
transmission / receive by DB-9.
Fig.6 NET101 Status LED Indicator
NET101 LAN Port LED Light indicators
Color
Condition / Description
Green
On: Internet correspond speed is 100M
Flash: Data transmitting / receiving
Yellow
On: Internet correspond speed is 10M
Flash: Data transmitting / receiving
Fig.7 NET101 LAN LED Indicator
