NET101 User’s Manual -9-
Chapter 4: Using Netility to Setup IP & Update Firmware
Chapter 4: Using Netility to Setup IP & Update Firmware
Section 1. Installing Netility
1. Insert the Utility CD into the CD-ROM drive and execute Netility.exe
2. After installation is completed, ‘Netility’ group will appear in Windows ’Start’ Æ
‘Program Group’.
Fig.8 Netility Group
3. Click “Netility” to start the program.
Section 2. Using Netility
The Netility main menu is shown below. The selection menu is located on the left. The
device, hardware, firmware and IP address connected to a LAN are displayed on the
right.
Fig.9 Netility Main Menu
2.1 Network Selection
Once Netility starts-up, it will automatically search for the computer’s Network card (If
not, click on “Network Selection” on the main menu to start the search). A pop-up
window will show the available Network Adapter.
Next, select the Network Adapter, which is connected to the LAN, and click ‘OK’ to
return to the main menu. NET101 will now appear in the main menu display area.
nSelect Network card in you system
r Conduct another search for
iCAMViews on network
o Configure iCAMView
p Update iCAMView Firmware
q About Netility
