NET101 User’s Manual -8-
Chapter 3: NET101
Step 3:
Connect the other end of
the Ethernet cable to
NET101 Ethernet port.
Step 4:
Connect the DC adapter
power output into
NET101 socket, and plug
the DC adaptor into the
wall socket
Step 5:
The LCD will display the
IP, Subnet Mask and
Gateway IP. Use a WEB
browser to login into the
IP address.
Warning:
Please make sure the input Voltage and Frequency of the DC power adapter (DC
5.3V) is correct before plugging into the power outlet!
