NET101 User’s Manual -20-
Chapter 5: NET101 Web Manager
Select the appropriate time zone for your area.
System Time (mm/dd/yyyy hh:mm:ss)
This section is to set NET101 System Time manually. The format is
pre-determined to: mm/dd/yyyy hh:mm:ss
2.2.4 Connection
This section determines the connection type for NET101.
i. Connect Status
Choose a mode for the current NET101.
Mode Description
Master Master mode is selected when the NET101 is used in a
one-on-one configuration with another NET101. The master
NET101 will define the communication baud rate, data length,
stop bit, etc. The slave NET101 will have the same exact
communication mode as the Master NET101.
Slave Slave mode is selected when NET101 is used in a one-on-one
configuration with the master NET101 or when connecting to
the virtual COM port driver. The communication baud rate,
data length, stop bit and others will all follow the instructions
from the Master NET101 or the virtual COM driver.
MODBUS gateway MODBUS gateway is selected when NET101 is used as a
gateway between the MODBUS on serial and the MODBUS
