DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
18 P.SEAT (D) 30 A Power seat
í
19 BTN 30 A For protection of various circuits
20 IG KEY2 40 A Starting system
21 BLOWER 40 A Blower motor
22 FUEL PUMP 25 A Fuel pump
23 ENGINE2 15 A Engine control system
24 EGI INJ 15 A Injector
25 PCM 10 A Engine control system
26 ENGINE
10 A *1
Engine control system
20 A *2
27 IG 20 A For protection of various circuits
28 TCM 20 A TCM
í
29 ESCL 10 A Electronic steering lock
30 IG KEY1 40 A For protection of various circuits
31 MAIN 125 A For protection of all circuits
32 DRL 20 A DRL
í
33 HAZARD 10 A Hazard warning flashers
34 ENG+B 10 A PCM
35 STOP 10 A Brake lights
36 HORN 15 A Horn
37 HEAD HI RH 15 A Headlight-high beam (Right)
38 HEAD LO RH 10 A Headlight-low beam (Right)
39 HEAD HI LH 15 A Headlight-high beam (Left)
40 HEAD LO LH 10 A Headlight-low beam (Left)
*1 2.5-liter engine
*2 3.7-liter engine
