Engine Compartment Overview
Automatic transaxle fluid-level dipstick
(only for automatic transaxle)
Brake/Clutch
fluid reservoir
Brake fluid reservoir
Power steering fluid reservoir
Power steering fluid reservoir
Engine oil-filler cap
Engine oil-filler cap
Windscreen washer
fluid reservoir
Windscreen washer
fluid reservoir
Fuse block
Battery
Engine oil dipstick
Engine oil dipstick
Fuse block
Battery
Engine coolant
reservoir
Engine coolant
reservoir
Automatic transaxle fluid-level dipstick
2.5-liter engine
3.7-liter engine
8-18
Maintenance and Care
Owner Maintenance
Mazda6_8Z64-EA-08H_Edition1 Page360
Wednesday, June 25 2008 10:5 AM
Form No.8Z64-EA-08H
