Manual Type
Temperature control dial Fan control dial Mode selector dial
A/C switch Air intake selector
qControl Switches
Temperature control dial
Cold Hot
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
MAX-A/C position
For quick cabin cooling, rotate the
temperature control dial counterclockwise
to the MAX-A/C position. The A/C
system automatically turns on and the air
intake mode switches to the recirculation
position automatically.
Fan control dial
Slow
Fast
6-6
Interior Comfort
Climate Control System
