3460 Fast’R
A-6
AccessWay Enclosure and Network Management
The AccessWay provides a network management interface to a
Motorola ISG 9000 NMS. Up to four AccessWays can be connected in
daisy-chain fashion to one NMS connection. A modem card must be
present in Slot 9 of each enclosure to transmit network management
information to and from other modems in the enclosure.
AccessWay Enclosure Connectors and
Interfaces
Modem Interface
AccessWay backplane interface and connectors are as follows.
Modems That Support Two-Wire Leased or Dial Connections
MODEM A and MODEM B Individual Connectors*
Interface: RJ-11
Connection Type: Two-Wire Leased or Dial Line
Pin Function
3 Ring
4 Tip
MODEM A and MODEM B Mass Line-Termination Connectors
Interface: RJ-21X.
Connection Type: Two-Wire Leased or Dial-Line
Pin Function
1 Slot 1 Modem Card Tip
26 Slot 1 Modem Card Ring
2 Slot 2 Modem Card Tip
27 Slot 2 Modem Card Ring
... ...
8 Slot 8 Modem Card Tip/
33 Slot 8 Modem Card Ring
9 - 17 None
34 - 42 None
*AccessWay backplanes labeled “Modem A/Modem B” do not support
four-wire leased-line connections.
