Page 5: Installation
2. Installation
Before installation, refer to the following lists to ensure that you have all the items shipped with the unit as well
as all other required items.
Standard Accessories
•
Mounting bracket hardware
Vertical – two removable flanges with four M4 screws and two mounting L-brackets with two
nut plates and four sets of screws and washers
Horizontal/Rack – two mounting L-brackets and four screws
•
RJ45 to RJ45 crossover cable
•
DB9F to DB25M modem cable
•
RJ45 to DB9F serial port adapter (for connection to standard DB9M DTE serial port)
•
Outlet retention clips, one per outlet (208-240V units only)
•
Separate power input cord
•
Power input retention bracket hardware
Two removable T-brackets with two 40mm screws.
Additional Required Items
• Phillip
screwdriver
•
Screws, washers and nuts to attach the unit to your rack
301-0399-4 Rev A. - Page 5
