MGE UPS Systems Switched PDU - Manual (Page 33)

3. Operations
Displaying user outlet, group and serial port access
The List User command displays all accessible outlets, groups and serial ports for a user.
To display user outlet, group and serial port access:
At the Switched PDU: prompt, type list user , optionally followed by a username. Press Enter .
Example
The following command displays information about the user JaneDoe:
Switched PDU: list user janedoe
Username: JANEDOE
Outlet Outlet
ID Name
.A1 DataServer_1
.A2 WebServer_1
Groups:
ServerGroup_1
ServerGroup_2
More (Y/es N/o): Y
Ports:
Port Port
ID Name
Console Console
JaneDoe may access the following outlets, groups and serial ports: outlet A1 which has a descriptive name of
DataServer_1, outlet A2 which has a descriptive name of WebServer_1, group ServerGroup_1 group
ServerGroup_2 and Console serial port.
Group Administration
Creating a group name
The Create Group command creates a new group name.
To create a group name:
At the Switched PDU: prompt, type create group , optionally followed by a descriptive name of up to 24
alphanumeric and other typeable characters (ASCII 33 to 126 decimal - spaces are not allowed. Group names
are not case sensitive). Press
Enter .
Example
The following command creates group name ServerGroup_1:
Switched PDU: create group ServerGroup_1
Removing a group name
The Remove Group command removes a group name.
To remove a group name:
At the Switched PDU: prompt, type remove group , optionally followed by a username. Press Enter .
Example
The following command removes group name ServerGroup_1:
Switched PDU: remove group ServerGroup_1
301-0399-4 Rev A. - Page 33
