T H E U N I N T E R R U P T I B L E P O W E R P R O V I D E R
Network Management Card – User Manual 34003991EN/GA - 9 -
Z Possibility of notification of status changes by e-mail, SMS or SNMP trap
Z Position detection of 2 dry contacts (maximum sensor/contact distance: 20 m)
Z Name and status of each configurable contact
Z Recording of events and measurements in the card log
Z Possibility of shutting down the installation in the event of a threshold being exceeded or on opening / closure of a dry contact
Z Connection to the card with straight CAT5 RJ45 network cables (maximum card/sensor distance: 20 m)
Z Hot installation
1.3.7 MIB (Management Information Base)
Z Compatible with MIB MGE V1.7
The list of objects managed can be found in the appendix
1.3.8 Default parameters
Function Parameter Default value Possible value
Network IP address 172.17.16.16 Network IP address
Subnet mask 255.255.0.0 Network IP address
Gateway Address 0.0.0.0 Network IP address
BOOTP/DHCP Enabled Active / Deactivated
Firmware Upload Enabled Active / Deactivated
SMTP server smtpserver 31 characters maximum
System UPS Contact Computer Room Manager 49 characters maximum
UPS Location Computer Room 49 characters maximum
History log interval (sec.) 60 5 to 99999 sec.
Environment log interval (sec.) 300 60 to 99999 sec.
Default Language English English / French / Spanish /
German / Italian
Manager table empty 50 maximum
Access control User name MGEUPS 10 characters maximum
Password MGEUPS 10 characters maximum
Community name read public 49 characters maximum
Trap port 161 Non configurable
Date and time Date and time adjustment Synchronise with an NTP server Synchronise with an NTP server
Synchronise manually
NTP server pool.ntp.org 49 characters maximum
Serial link Speed 9600 baud Non configurable
Data bits 8 Non configurable
Stop bits 1 Non configurable
Parity without Non configurable
Flow control without Non configurable
