Network Management Card – User Manual
34003991EN/GA
- 6 -
1.1.4.1 How to connect UPS / agent / network:
Insert the optional card in the UPS and connect the UPS to the computer network.
Start the MGE UPS, then the computers.
1.1.4.2 Setting up the protection:
Set up the Network Management Card (see user manual).
Install and configure the Network Shutdown Module on all machines that are to be protected by the UPS.
The software components for each platform and the user manuals are on the Solution-Pac-2 CD or are available for download on the
“
1.2 Presentation of the Network Management Card (NMC)
1.2.1 Compatibility with UPSs
The Minislot Network Management Card is compatible with the following UPSs:
Pulsar Evolution 500 / 800 / 1100
From technical level
06
Pulsar Evolution 2200 / 3000
From technical level
05
Pulsar Evolution 1500
From technical level
05
EXtreme C 700 / 1000 / 1500
From technical level
B2
EXtreme C 2200 - 3200
From technical level
02
Pulsar EX 700 / 1000 / 1500 RT (US°)
From technical level
03
Pulsar EX 2200 / 3200 (US°)
From technical level
09
Pulsar M 2200 / 3000
All models
Pulsar 700 / 1000 / 1500
All models
Note:
If the UPS's NT is below that indicated in the table above, contact MGE's technical support.
The Network Management Card (66102) is not compatible with Pulsar EX 7/10, Pulsar EX 15/20/30, Pulsar ESV+, 8/11/14/22 ranges.
Network Management Cards acquire information on the operation status of the UPS systems and provide remote control of these systems by
means of an ETHERNET network from any SNMP administration station or Web browser.
They also supply alarms to the Network Shutdown Modules to trigger shutdown or other automatic actions for protected servers.
Network Management Cards are compatible with the "Enterprise Power Management" supervision system and with the MGE UPS SYSTEMS
network protection system.
