T H E U N I N T E R R U P T I B L E P O W E R P R O V I D E R
Network Management Card – User Manual 34003991EN/GA - 55 -
Load not powered Load powered
UPS internal fault UPS OK
Battery fault Battery OK
UPS overload UPS returns to normal load
UPS overtemperature UPS temperature OK
Imminent UPS shutoff UPS OK
: Temperature is above high threshold xx °C : La température est au dessus du
seuil haut xx °C
: Humidity is above high threshold xx % : L'humidité est au dessus du seuil
haut xx %
: Temperature is below low threshold xx °C : La température est en dessous du
seuil bas xx °C
: Humidity is below low threshold xx % : L'humidité est en dessous du seuil
bas xx %
: :
: :
: :
: :
7.1.2 Table of UPS events
List of time dated informations
Alarm on Alarm off
Battery fuse blown Battery fuse OK
Battery temperature fault Battery temperature OK
Battery charger fault Battery charger OK
Charger temperature fault Charger temperature OK
End of Warranty LCM message OK
End of battery life LCM message OK
End of life of the wearing parts LCM message OK
Outlet 1 open Outlet 1 closed
Outlet 2 open Outlet 2 closed
Chopper fault Chopper OK
Normal AC switch (Q1) open Normal AC switch (Q1) closed
Normal AC frequency out of tolerance Normal AC frequency OK
Normal AC fuses blown Normal AC fuses OK
Normal AC module fault Normal AC module OK
Normal AC voltage out of tolerance Normal AC voltage OK
Automatic Bypass switch (Q4S) open Automatic Bypass switch (Q4S) closed
Bypass AC frequency out of tolerance Bypass AC frequency OK
Automatic Bypass fault Automatic Bypass OK
Automatic Bypass overload Automatic Bypass load OK
Automatic Bypass overtemperature Automatic Bypass temperature OK
Bypass AC phase out of tolerance Bypass AC phase OK
Automatic Bypass thermal overload Automatic Bypass load OK
Load not protected - On Automatic Bypass Load protected - Return from Bypass
Bypass AC voltage out of tolerance Bypass AC voltage OK
