25
At a glance
Instrument cluster
Item Page
1 Coolant temperature gauge 135
2 Fuel gauge with fuel tank
reserve warning lamp
331
3 L Left turn signal
indicator lamp
53
K Right turn signal
indicator lamp
53
4 Speedometer with:
v Electronic Stability
Program (ESP ® )
warning lamp
333
l Distance warning
lamp
Vehicles without Distronic*:
Warning lamp without func-
tion. It illuminates when the
ignition is on. It should go out
when the engine is running.
332
5 Tachometer 136
Item Page
6 Right display with:
< Seat belt telltale 333
A High beam headlamp
indicator lamp
52
- Antilock Brake
System (ABS)
indicator lamp
328
7 J Reset button 134
8 Display with:
ț Gear selector lever
position 166
ț Program mode 166
ț Digital clock
(see COMAND operating
instructions)
9 Multifunction display with:
ț Trip odometer 137
ț Main odometer 137
Item Page
a Outside temperature
indicator
136
b Left display with:
1 Supplemental
Restraint System
(SRS) indicator lamp
335
; Brake warning lamp,
USA only
329
3 Brake warning lamp,
Canada only
329
? Engine malfunction in-
dicator lamp,
USA only
330
± Engine malfunction in-
dicator lamp, Canada
only
330
H Tire inflation pressure
warning lamp
334
c Knob for instrument cluster il-
lumination
134
