SPECIFICATIONS
DVR
Video format NTSC/EIA or PAL/CCIR
Hard disk storage IDE type, UDMA 66, supported 250 GB HDD
Record mode Manual / Alarm / Timer / Motion
Camera Input Signal Composite video signal 1 Vp-p 75Ω BNC, 4 channels
Camera Loop Back Composite video signal 1 Vp-p 75Ω BNC, 4 channels
Main Monitor Output Composite video signal 1 Vp-p 75Ω BNC
Call Monitor Output
Composite video signal 1 Vp-p 75Ω BNC
Audio input 4 audio inputs, (RCA) *
Audio output 2 audio outputs, (RCA) **
Motion Detect Area 15 * 12 targets per camera (NTSC) / 15 * 14 targets per camera (PAL)
Motion Detect Sensitivity 256 Levels
Video Loss Detection Yes
Refresh Rate Up to 120 images/sec. for NTSC / 100 images/sec. for PAL
Recording Rate Up to 25 images/sec. for NTSC / 18 images/sec. for PAL
Dwell Time Programmable (1~10 Sec)
Picture in Picture Yes (Movable)
Key Lock
Yes
Picture Zoom 2*2 (Movable)
Camera Title 6 letters
Video Adjustable Color/ Contrast/ Brightness Adjustable
Alarm Input TTL input, Hi (5V), Low (GND)
Alarm Output COM,/N.O
Remote Control RS-232 or RS-485
Time Display Format YY/MM/DD, DD/MM/YY, MM/DD/YY, OFF
Power Source AC100~240V + 10% switching adaptor
Power Consumption <32W
Operation Temperature
10 ~ 40 ℃
RS-232C / RS-485 (bps)
115200 、 57600 、 19200 、 9600 、 4800 、 3600 、 2400 、 1200
Dimension (mm) 430(W) x 300(D) x 65(H)
Net Weight
5.4 k gs
Specifications are subject to change without notice.
✻ 4 audio inputs, but only can select 1 during operation for recording
✻ ✻ with 2 mono audio outputs from the same source.
18
