PICTURE IN PICTURE (PIP)
Press PIP button to enter PIP display screen. The PIP format displays a full screen “background” picture
with a 1 / 16 size screen “insert”.
Æ Press button to move the insert screen.
Æ Press “Enter” button to confirm the camera selection.
Æ Press “Left” or “Right” to choose background or insert screen.
Æ Press camera select (1-4) to select appointed camera into screen.
Æ Press “Menu“ to exit
ZOOM
Press ZOOM button to enlarge the display of main picture. It displays zoomed picture on main picture and a
small window inserted. The inserted window contains a movable 1/4 view size of the appointed camera.
Æ Press the appointed “Camera Select (1-4)“.
Æ Press “Zoom“ button to select zoom mode.
Æ Press the “Zoom” button again to move the zoom pointer.
Æ Press “Menu“ to exit.
VIDEO LOSS
Screen will display if the video input is not connected properly.
SEARCH
1. LAST RECORD
Play the last recorded piece of video.
2. FULL LIST
Show a listing of all recorded video on the HDD which sorted by time.
3. ALARM LIST
Show a listing of all recorded video triggered by an Alarm.
NOTE : If there are no Alarm in the record, the screen will
display “EMPTY”.
4. MOTION LIST
Show a listing of all motion detection triggered.
5. TIME SEARCH
Find video recorded on a specific date that is entered.
16
OPERATION OPTIONS
Advanced Operation
► M 2002-JAN-02 01:02:03 M-HDD
M 2002-JAN-01 05:02:03 M-HDD
A 2002-JAN-01 04:02:03 M-HDD
T 2002-JAN-01 03:02:04 M-HDD
D 2002-JAN-01 02:02:03 M-HDD
M 2002-JAN-01 01:02:01 M-HDD
◄
: PAGE UP►: PAGE DOWN
D : Motion Record
M : Manual Record time
A : Alarm Record time
T : Timer Record time
M-HDD : Stored on Master HDD
► LAST RECORD
FULL LIST
ALARM LIST
MOTION LIST
TIME SEARCH
