12. CLEAR HDD
Delete all the contents of your HDD. When you choose “YES” on this option, you will be prompted with the
question shown : Press “►” to clear HDD or press ”◄” to confirm not to clear HDD.
13. SYSTEM RESET
Reset all system settings back to factory default settings.
14. REMOTE MODE
Set the remote mode for connection with computer via RS-232 or RS-485. (Please refer to page.17 for RS-232
Remote Protocol)
15. BAUD RATE
Set the remote protocol transmitting baud rate. Available Baud Rate are 115200, 57600, 19200, 9600, 4800,
3600, 2400 and 1200.
16. REMOTE PROTOCOL ID SETUP
To control different DVR by setting RS232 remote protocol. ID number can be set from 000 to 255.
ALL DATA IN HDD
WILL BE CLEARED
ARE YOU SURE?
(◄ : NO ► : YES )
TIMER
1. DAY
Select the day, or days of the week (Mon–Fri / Sat-Sun / Daily) that you wish to schedule
the DVR to automatically record.
NOTE : 1.Special Date could be changed by “Enter”, “Up” and “Down” buttons.
2. If you have selected the specific date and recording timer set from that specific day to a new day,
then the Recording Timer Schedule will be set as whole week. For specific date of Recording Timer
Schedule, it is not recommended to set End Time over 23:59. For Example:If you set Timer Schedule
Day as Sunday, and START from 11:30, but End on 00:20, then Recording Timer Schedule is set as
from every Sunday's 11:30 to next Sunday's 00:20. If you only want to set Recording Timer Schedule
from every Sunday 11:30 to Monday 00:20, then you should set Recording Timer Schedule as Sunday
from 11:30 to 23:59, and Monday from 00:00 to 00:20.
2. START
Select the starting time for the recording.
3. END
Select the finishing time for the recording.
4. QUALITY
Select the image quality for the recording. There are four Quality settings :
BEST, HIGH, NORMAL and BASIC.
5. IPS
Stands for Images Per Second and it could let you see Record submenu
for more details.
NTSC－25A、15、8、4、2、1
PAL－18A、12、6、3、2、1
NOTE : “A” means “ Record with Audio”.
6. TIMER ENABLE
Enables / disables Timer recording function
(MENU)
► TIMER
RECORD
CAMERA
SYSTEM
EVENT
(TIMER)
DAY START END QUALITY IPS
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
DAILY 00:00 00:00 BEST 25A
TIMER ENABLE : YES
Note: If timer recording is enabled then manual
recording is disabled; so if you have interrupted the timer
recording to playback you simply press record and this
reinitiates the timer record mode. This would effectively
mean that manual record was disabled during timer record
enable mode. Only timer would be active.
