MENU OPTIONS
DVR
SYSTEM
1. AUDIO INPUT
To choose one of 4 channels to record. (
only can select 1 during operation for recording
)
(MENU)
TIMER
RECORD
CAMERA
► SYSTEM
EVENT
2. INT AUDIBLE ALARM
To set the INTERNAL AUDIBLE ALARM. It will be triggered by event occurrence when
the setting is ON.
11
5. ALARM DURATION
Set the reaction time which was determined by how long the
alarm mode responded to a buzzer. Default setting is 10 sec.
Options are 10 SEC, 15 SEC, 20 SEC, 30 SEC, 1MIN, 2MIN,
3. EXT AUDIBLE ALARM
To set the EXTERNAL AUDIBLE ALARM. It will be triggered by event occurrence
when the setting is ON.
4. MOTION AUDIBLE ALARM
To set the MOTION AUDIBLE ALARM. It will be triggered by motion detection
occurrence when the setting is ON.
(SYSTEM)
► AUDIO INPUT : 1
INT AUDIBLE ALARM : ON
EXT AUDIBLE ALARM : ON
MOTION AUDIBLE ALARM : ON
ALARM DURATION : 10 SEC
DWELL TIME : 02 SEC
MESSAGE LATCH : NO
TITLE DISPLAY : ON
TIME DISPLAY : Y/M/D
2003-JAN-02(THU) 17:37:09
NEW PASSWORD : XXXX
CLEAR HDD : MASTER
SYSTEM RESET : NO
REMOTE MODE : RS-232
BAUD RATE : 9600
REMOTE ID : 000
3 MIN, 5 MIN, 10 MIN, 15 MIN, 30 MIN, ALWAYS.
6. DWELL TIME
DWELL TIME is the time period that each channel sequentially
shown on call monitor.
7. MESSAGE LATCH
To select whether the DVR messages will disappear after 10
sec or remain on screen. NO is the default setting which the
messages will go away after 10 sec.
NOTE : Video loss, Alarm and Motion messages will be shown
the same as Alarm Duration time.
8. TITLE DISPLAY
To set the title shown on monitor or not.
9. TIME DISPLAY
To set the time format on the DVR.
10. TIME
To set the correct time on the DVR.
11. NEW PASSWORD : XXXX (Default password : 0000)
To set the new password.
