Service Manual
Alignment & Troubleshooting
4-7
4.1.2.2 Clearing Paper Jams
When a paper jam occurs, "Paper Jam" appears on the display. Refer to the table below to locate and clear the paper jam.
To avoid tearing the paper pull the jammed paper out gently and slowly. Follow the steps on the next pages to clear the jam.
4.1.2.2.1 In the Paper Tray
1) Open and close the front cover. The jammed paper is automatically ejected from the machine. If the paper is not ejected
continue to step 2.
2) Pull the paper tray open.
Message
Location of Jam
Paper Jam 0
In the paper tray.
Paper Jam 1
In the fuser area or around the toner
cartridge.
Paper Jam 2
In the paper exit area
Bypass Jam
In the manual feeder
