Disassembly and Reassembly
3-12
1. Before you remove the Sub Hook PBA, you should
remove:
- Rear Cover (see section 3.3)
- Side Cover L (see section 3.4)
2. Unplug the one connector from the Sub Hook PBA,
as shown below.
3. Remove the one screws securing the Sub Hook PBA
and remove it.
3.14 Sub Hook PBA
Sub Hook PBA
