Monessen Hearth CSDV40SLP - Manual (Page 41)

58D6056
41
CSDV Series Direct Vent Gas Stove REpLACEmENT pARTS
Ref. Description qty. CSDV40NV CSDV40pV
1. Burner Assembly 1 58D0368 58D0368
2. Rear Burner Assembly 1 58D0362 58D0362
3. Log Support Bracket 1 58D0310 58D0310
4. Pilot Assembly 1 20H2048 20H2048
5. SIT 820 Nova Valve 1 37D0117 37D0118
6. Front Injector 1 20H3150 20H3151
7. Rear Injector 1 62D3006 33D4046
8. Venturi 1 45D0600 45D0600
9. ON/OFF Rocker Switch 1 41D0048 41D0048
10. Ceramic Glass 1 58D0320 58D0320
11. Air Shutter Rod 1 58D0048 58D0048
12. Air Shutter Knob 1 45D0237 45D0237
13. Knob Extension Hi/Lo 1 43D0095 43D0095
14. Knob Extension ON/OFF 1 43D0094 43D0094
15. Ignitor Battery Module 1 45D0077 45D0077
16. Ignitor Wire Harness 1 45D0500 45D0500
17. ON/OFF Wire Harness 1 45D0501 45D0501
18. Rear Burner Tube 1 58D0366 58D0366
19. 5/16 Brass Tee 1 43D0181 43D0181
20. Front Burner Tube 1 58D0364 58D0364
21. Valve Tube 1 58D0365 58D0365
22. Rear Log 1 58D1921 58D1921
23. Right Bottom Log 1 58D1923 58D1923
24. Right Top Log 1 58D1925 58D1925
25. Left Top Log 1 58D1924 58D1924
26. Left Bottom Log 1 58D1922 58D1922
27. Top Mid Log 1 58D1926 58D1926
28. Vertical Restrictor (not shown) 1 45D0551 45D0551
29. Engine Gasket Set (not shown) 1 58D0194 58D0194
30. Front Grate (not shown) 1 58D0369 58D0369
W
ARNING
Failure to position the parts in accordance
with these diagrams or failure to use
only parts specifically approved with this
appliance may result in property damage
or personal injury.
ACCESSORIES
Thermostat Blower - MODEL #BLOTCS
(available on CSDV30 and CSDV40 only)
