Monessen Hearth CSDV40SLP - Manual (Page 31)

58D6056
31
CSDV Series Direct Vent Gas Stove OpERATING INSTRUCTIONS
OF
F
PILO
T
ON
PILOT
FP1937
control knob on
mAIN BURNER SWITCH
The “ON/OFF” switch for the main burner can be found on the back right
side of the stove. This switch allows you to turn on and to turn off the main
burner without using the gas valve knob. Make sure the button is in the
“ON” position to light the main burner. Figure 43
LIGHTING THE BURNER
Depress and turn the knob counterclockwise
to the “ON” position.
Figure 44. It will take less than four (4) seconds for the burner to ignite.
pILOT pOSITION
Depress and turn knob to pilot position to keep burner off while maintain-
ing the pilot light. Figure 45
Depress and turn knob clockwise to “OFF” position. Figure 46
TO TURN OFF GAS
Figure 45 -
Pilot Position
LIGHTING BURNER
PILOT
OF
F
PILOT
O
N
PILOT
OF
F
P
IL
O
T
ON
FP1935
control knob pilot
Figure 46 -
Off Position
Figure 44 -
On Position
Figure 43 -
On/Off/RS Switch
OFF
ON
ST1148
on off switch
