CSDV Series Direct Vent Gas Stove
VENTING INSTALLATION
H
V
V
1
ST1146
vert vent 2 elbows
N O T E : I n s t a l l
restrictor into 4"
collar of stove or
first vent section
as shown.
Table 6 - Venting with Two (2) 90° Elbows
maximum
minimum
minimum
minimum
Horizontal (H) CSDV20 (V) CSDV30 (V) CSDV40 (V)
24"
41Z\v"
44C\v"
48C\v"
(610 mm)
(1048 mm)
(1137 mm)
(1238 mm)
20'
95Z\v"
98C\v"
102Z\v"
(6 m)
(2419 mm)
(2508 mm)
(2597 mm)
Figure 30 -
Vertical Rigid Venting
Configuration using Two (2) 90°
Elbows
NOTE: Vertical (V)
+ Vertical (V
1
) = 20'
(6 m) Maximum
V
ST1147
vert vent
NOTE: Install restrictor
into 4" collar of stove
or first vent section as
shown.
Figure 31 -
Vertical Rigid Venting Configuration with
No Horizontal Run
ST1147
Vertical
Venting (V)
= 40' (12 m)
Maximum
SImpSON DURAVENT GS 4" x 6B\," (BLACK pIpE)
Number
Description
902B
6B\," x 48" Pipe
903B
6B\," x 36" Pipe
904B
6B\," x 24" Pipe
906B
6B\," x 12" Pipe
907b
6B\," x 9" Pipe
908B
6B\," x 6' Pipe
911B
6B\," Adjustable (11" - 14B\," Pipe)
940
Wall Thimble
941
Cathedral Ceiling Support Box
943
Roof Flashing 0/12 - 6/12
943S
Roof Flashing 7/12 - 12/12
945B
6B\," x 45° Elbow
950
Vinyl Siding Standoff
953
Storm Collar
963
Ceiling Firestop
981
36" Snorkel Termination
984
Horizontal Termination Vent Cap
988
Wall Strap
990B
6B\," x 90° Elbow
991
Vertical High Wind Termination
