Page 17
58D6056
17
CSDV Series Direct Vent Gas Stove
HOT
H
V
ST1139
Horizontal termination
VENTING INSTALLATION
Figure 21 -
Horizontal Termination Configuration for
Rigid Venting Using One (1) 90° Elbow
ST1139
Table 2 - Horizontal Venting
maximum
Vertical
Vertical
Vertical
Horizontal (H)
minimum
minimum
minimum
CSDV20 (V) CSDV30 (V) CSDV40 (V)
24"
41Z\x"
52Z\x"
54Z\x"
(610 mm)
(1054 mm)
(1334 mm)
(1384 mm)
20'
95Z\v"
98C\v"
102Z\v"
(6 m)
(2419 mm)
(2508 mm)
(2597 mm)
NOTE: Add 1/4" rise per 12" horizontal length of pipe.
NOTE: This configuration is for use with corner
installation also.
H
1
H
V
ST1140
Horiz term 2 elbows
Figure 22 -
Horizontal Termination Configuration for Rigid Venting Using
Two (2) 90° Elbows
Table 3 - Horizontal Venting with Two (2) 90° Elbows
maximum
Horizontal
Vertical minimum
H + H
1
CSDV20 (V) CSDV30 (V) CSDV40 (V)
24"
41Z\x"
52Z\x"
54Z\x"
(610 mm)
(1054 mm)
(1334 mm)
(1384 mm)
20'
95Z\v"
98C\v"
102Z\v"
(6 m)
(2419 mm)
(2508 mm)
(2597 mm)
NOTE: Add 1/4" rise per 12" horizontal length
of pipe.
ST1140
