9
Smart DeskStream Technical Presentation 9
1. Use HSTR uplinks to increase
backbone access
n
Resilience, load sharing and higher
access speeds
2 x 100Mbps
Powerful, Flexible Connectivity
Resilience and Performance
Switched User Ring
Network
Backbone
If bandwidth still needs to be extended, the DeskStream supports
HSTR uplink modules - both copper and fibre. These only work as a
point to point full duplex link and so potentially will allow a 200Mbps
connection.
