Smart DeskStream Technical Presentation 21
n Bottom DeskStream
n Automatically configures itself as Master
n Assumes responsibility for stack management
n TrueView sees the stack as a single icon
n Uses Master mgmt MAC address or LAA
l Mgmt MAC is same as base MAC address
n Single IP address per stack
n Single download image,
l Master takes care of upgrade to all DeskStreams in
the stack
l Active download
l Uses this microcode after reset
Connectivity
Stacking Module - 2
Trueview displays a single icon for each stack. Opening the icon
shows the individual units in the stack.
