Smart DeskStream Technical Presentation 38
Diagnostic Downloads
n Self-tests run on every reboot
n Output is sent over serial port as it runs
n On failing,
l The test will halt
l The Status LEDs will flash to signify an error
l The failing test message will be re-sent to the serial port
every 15 seconds
l A terminal can then be connected to see the error
n Output can be provided to Madge Support for
problem diagnosis
n Allows simple and quick diagnosis of problems
Smart DeskStream
Diagnostic Features
