38

CHAP. 6 Network Setup

3) Dynamic IP of PPPoE (DSL)

DVR doesn’t support DSL (PPPoE), user have to set NETWORK with IP SHARE if
user need to access DVR remotely. At this time, User have to port forward on DVR.
Please contact IP SHARE Manufacturer if you need to know how to forward port.

Even though user have Static/Dynamic IP, if user want to use another device
(PC) through IP SHARE, user can set NETWORK as follows,

1. Verify if IP address is OK or not with PC before connecting DVR.
2. Connect Router (IP SHARE) to DSL modem as shown the following picture.
3. Set the internet connection on Router (IP SHARE). (Refer to the Router Manual.)
4. Verify if sub-group of network in Router is OK or not.
5. Connect DVR to Router.
6. DVR : MENU

EXTERNAL DEVICE

TCP/IP

7. Set DHCP to MANUAL and go into TCP/IP SETUP.
8. Verify if MAC ADDRESS starts from 00-0A-A2….
9. Input internal IP address which user assigned from Router.
10. Set IP PORT. (50000 recommended)
11. Input GATEWAY of Router.
12. Input SUBNET MASK of Router.
13. Go out of MENU SETUP.
14. Forward port from Router. (Refer to the Router Manual.)
15. Access DVR with external IP and Port (Port forwarded).

* If Router support DDNS, user can access Remote Viewer using Domain Information.

* If user fail to access, please verify 1, 4, 15 again.

* When speed is too slow and connection fails after access : MENU

EXTERNAL

DEVICE

TCP/IP SETUP

CONNECTION SETUP

Increase value of Timeout to find the most suitable speed.

Remote Viewer

(Client)

DSL Modem
(Dynamic IP)

Internet

Internet

Internet

Internet

Router

or Gateway

(IP Share)

LAN

LAN

LAN

LAN

LAN

LAN

LAN

LAN

DVMR

(Server)
