4-7. Search

Press [SEARCH] button, and 3 different methods for searching recorded data are available as shown
in following SEARCH window. For selecting searching method, use direction key or Jog/Shuttle.
After selecting each search method, press [ENTER] button for playback. exit, press [MENU] button.

1) SEARCH BAR

Search by percentage of total recorded data. It starts from image corresponding to set % of data
on the search bar.

2) TIME/DATE

Search by time & date. Playback starts from the time & date selected.

3) EVENT LIST

Search by event list (Motion, Alarm, Video Loss).

4-8. PAN/TILT/ZOOM Camera Operation

Press [PTZ] button first for PTZ control mode. Numeric buttons from 1 to 16 and direction buttons are
assigned for each PTZ command, and user can control PTZ camera connected to DVR unit by
pressing any one of those 20 buttons, one after the other, as needed, and it is just like control by
separate PTZ controller.

SEARCH BAR

TIME/DATE

EVENT LIST

SELECT MENU : ▲▼, & [ENTER]

SEARCH BAR

[START] 2006/JUN/15 AM11:34:34

[ END ] 2006/JUN/15 PM02:50:45

[TARGET DATE/TIME]

020 %

SELECT: JOG, SHUTTLE

SEARCH : [ENTER], EXIT : [MENU]

TIME/DATE

[START] 2006/JUN/20 AM04:04:12

[ END ] 2006/JUN/20 PM08:12:23

INPUT TIME/DATE

2006/JUN/07 AM04:04:12

SEARCH : [ENTER], EXIT : [MENU]

SEARCH page

SEARCH BAR page

TIME/DATE page

EVENT LIST page

EVENT LIST

SEARCH : [ENTER] , EXIT : [MENU]

EVENT

TIME/DATE

001/001

----

---- / - -/ --

-- : -- : --

SELECT: ▲▼, PAGE:+-
