CHAP. 5 Set Up

4) SPOT MONITOR SETUP

(1) SWITCHING INTERVAL

Channel switching time (01 sec. ~ 99 sec.)

(2) ALARM POP-UP

When ALARM is detected, the image of channel
connected with Alarm sensor pops up.
Set ALARM detection pop-up (ON/OFF)

(3) MOTION POP-UP

Set MOTION detection pop-up (ON/OFF)

※

EVENT POP-UP DURATION

Set EVENT POP-UP DURATION

SPOT MONITOR SETUP

SWITCH INTERVAL 03 SEC
ALARM POP UP ON
MOTION POP UP ON
EVENT POP UP DURATION 01 SEC

SELECT: ▲▼, CHANGE VALUE : + -

5) AUDIO SETUP

AUDIO SETUP

CH REC PLAY

01 ON ON
02 ON ON
03 ON ON
04 ON ON

SELECT: ▲▼◀▶, & [ENTER]

Use direction button to move to channel and Press [ENTER] button to set (ON/ OFF).

1) REC

(1) ON : Record images with AUDIO

(2) OFF : Record images without AUDIO

2) PLAY

(1) ON : Recorded sound comes out during

playback

(2) OFF : Recorded images only play back

If events (MOTION or ALARM) happen on several channel at the same time, channel No. 1 has the
first priority to pop up. For example, if events happen on channel No. 1, channel No. 2, and channel

No. 4 at the same time, channel No. 1 pops up. If the motion disappears on channel No. 1, then channel

No. 2 pops up for the duration that you set. However, even though motion happens on channel No. 1

again within the duration, channel No. 2 still displays. If motion on channel No.1 keeps on going even after

the duration, channel No. 1 pops up again.
