Page 8

8
74D0009
A
N
F
C
K
L
J
I
31 7/8
3
M
B
D
E
H
G
15/16
11 3/8
PRE-INSTALLATION INFORMATION
Figure 3 - Fireplace Dimensions
FIREPLACE DIMENSIONS
E
H
J
A
D
L
K
C
F
N
M
B
I
G
DESCRIPTION
Key
Letter BLDV400
BLDV500
Overall Front Width
A
37
1
/
16
" 41
1
/
16
"
Inside
Width
B
31
15
/
16
" 35
15
/
16
"
Glass Width
C
29"
33"
CTR
Pipe
D
18
9
/
16
" 20
9
/
16
"
Rear Width
E
30
1
/
4
" 34
1
/
4
"
Glass Height
F
25
13
/
16
" 25
13
/
16
"
Chassis Height
G
37
1
/
2
" 37
1
/
2
"
Depth
H
17
9
/
16
" 17
9
/
16
"
Height to Standoffs
I
40
5
/
8
" 40
5
/
8
"
CTR
Height
J
7
5
/
16
" 7
5
/
16
"
Top
Face
K
7
3
/
4
" 7
3
/
4
"
Side
Face
L
2
9
/
16
" 2
9
/
16
"
Bottom
Face
M
1"
1"
Overall Front Height
N
40
5
/
8
" 40
5
/
8
"
