MicroNet Technology SP3367N - Manual (Page 7)

y If users want to place this router at high places, please make sure the router is
firmly secured. Falling from high places would damage the router and its
accessories, and in such cases, the warranty will be void.
y
Accessories of this router, like antenna and power supply, are danger to small
children under 3 years old. They may put the small parts in their nose or month
and it could cause serious damage to them.
y The router will become hot when being used for long time (This is normal and is
not a malfunction). Do not put this router on paper, cloth or other flammable
materials.
y
There’s no user-serviceable part inside the router. If users found the router is not
working properly, please contact the authorized dealer of purchase. Do not
disassemble the router, otherwise warranty will be void.
y If the router falls into water when it’s powered on, do not use hands to pick it up.
Switch the electrical power off before doing anything, or contact an experienced
technician for help.
y If users smell something strange, or even see some smoke coming out from the
router or power supply, remove the power supply or switch the electrical power off
immediately, and call authorized for help.
1.4 Specifications
Standards
z
ADSL
¾
ITU-T G.992.1 (G.dmt), G.992.2 (G.lite),
G.992.3 (ADSL2), G.992.4 (splitterless
ADSL2), G.992.5 (ADSL2+) for Annex A,
B.
¾
Multi-Mode standard (ANSI T1.413,
Issue 2; G.dmt (G.992.1); G.994.1 and
G.996.1 (for ISDN only); G.991.1;G.lite
(G992.2))
z
Wireless
¾
IEEE802.11n Draft
¾
IEEE802.11b/g
Memory
z
Flash: 2MB NOR Flash
z
RAM: 8MB SDRAM
Interface
z
4 x 10/100M UTP Ports
z
1 x ADSL RJ-11 Port
Antenna 3 x RP-SMA Antenna
MIMO Technology 2T3R
Transmit Power
z
11n: 15dBm
z
11g: 15dBm
z
11b: 18dBm
DHCP DHCP Server and Client
Advance Features
z
NAT (Network Address Translation)/ NAPT IP
4
