Parameter Description
IP/MAC Filter Set
Index
This is the item number to record the setting.
Interface Select which channel (PVC) to configure.
Direction
Select the access to the Internet (Outgoing) or from the
Internet (Incoming), or Both.
IP / MAC Filter Rule Editing
Parameter Description
IP/MAC Filter Rule
Index
This is the item number to record the setting rule.
Rule Type Select to filter through the IP Address or MAC Address.
Active
Select “Yes” to enable the current rule, select “No” to cancel
the current rule.
Source IP Address
Enter the start IP Address which will be monitored. If “0.0.0.0”
is set, it means for any IP Address.
Subnet Mask Enter the Subnet Mask based on the Source IP Address.
Port Number
LAN users use port number to distinguish one network
application over another such as 21 is for FTP service. The
port number range is from 0 to 65535. It is recommended that
this option be configured by an advanced user.
Destination IP
Address Enter the start IP Address which will be monitored. If “0.0.0.0”
is set, it means for any IP Address.
Subnet Mask Enter the Subnet Mask based on the Destination IP Address.
Port Number This is the port or port ranges that define the application.
Protocol
It is the packet protocol type used by the application. Please
select “TCP”, “UDP” or “ICMP”. For example, FTP service,
you have to select “TCP”.
Rule Unmatched
Select action for the traffic mismatching current rule.
“Forward” is to leave it pass through. “Next” is to check it by
the next rule.
Application Filter
